Has Distortion AI Robot Surveillance Camera Binocular Recognition Lens

Has Distortion AI Robot Surveillance Camera Binocular Recognition Lens

Brand Name: HCVsight
Model Number: HC-JB3.6
MOQ: negotiable
Price: negotiable
Payment Terms: T/T
Supply Ability: 100000/pieces/mouth
Detail Information
Place of Origin:
ShenZhen,China
Video Capture Resolution:
1080P
Sensor Type:
CMOS
Product Dimensions:
12mmX13mm
Color:
Black
Pixel:
2MP
Compatibility:
Windows/Mac/Linux/Andriod
Lens Type:
Customizable
Packaging Details:
Anti-static bag in Paper box(110mmx93mm41mm)
Supply Ability:
100000/pieces/mouth
Highlight:

AI Robot Camera Module Lens

,

Surveillance Camera Module Lens

,

1080P binocular lens

Product Description



Has Distortion AI Robot Surveillance Camera Binocular Recognition Lens

Product Description:

The camera module lens is equipped with a 1/2.7“-inch IMX12 sensor, a CMOS sensor known for its high-quality image processing capabilities. The sensor is capable of capturing images with a resolution of 2MP, ensuring your images are always clear and sharp. Whether you use it as a car camera lens, aerial camera lens, or any other application, you can be sure that your images are always of the highest quality. One of the main features of the camera module lens is its TV distortion of <-1.0%. This means the lens is able to capture images with minimal distortion, ensuring your images are always accurate and realistic. This is a vital feature for those using the lens for automotive camera lens or aerial camera lens applications where accuracy is critical. The camera module lens is very easy to use and perfect for both amateur and professional photographers. Just connect it to your device and start shooting.

Lens parameters:



TTL 15.9
EFL 3mm
F/NO 2.0
BFL 3mm
MBF 2.64mm
Aperture F2.2
M.O.D 0.2mm
Consturction 4E+IR
FOV Sensor size 1/2.7"
Distortion <-1.0%
CRA <17°
Angle: D=95°
H=83°
V=55°
Relative illumination:-
Resolution 5 Megapixel
Thresd Size M12XP0.5

Product advantages and application scenarios:



1,Signal stability, many years of small camera module development and design experience, to avoid a lot of signal interference factors

2,Good compatibility,camera module is compatible with various operating systems, windows system, Android system, linux system, Raspberry Pi, etc.

3, High color reduction degree, decades of debugging experience of software engineering department, lighting, outdoor sunshine, stairwell dark state, look at faces, see green plants, look at flames and other simulated different environments for camera color debugging. Make the color reduction degree to achieve the best.

Products used to a variety of machine vision, equipment monitoring. Such as: ATM, bank to open an account, queuing, hospital inspection report, printer, vending machines, advertising machine, all-in-one, electronic said, robot, crane, patch machine, automatic welding equipment, fire water cannon, law enforcement instrument external, android mobile phone external camera, computer camera, security surveillance cameras, coal power boiler flame monitoring, certification than equipment, high meter and other machine equipment embedded.

Customization:



Brand Name: HCVsight

Model Number: HC-JB3.6

Place of Origin: ShenZhen,China

Minimum Order Quantity: negotiable

Price: negotiable

Packaging Details: Anti-static bag in Paper box(110mmx93mm41mm)

Delivery Time: 2-3weeks

Payment Terms: T/T

Supply Ability: 100000/pieces/mouth

Color: Black

Compatibility: Windows/Mac/Linux/Andriod

Customization Services: USB camera module, AHD camera module, CVBS camera module, wired webcam module, wireless wifi camera module, etc.

High pixels, 1mp 2mp 4mp 5mp 8mp 12mp and other highest pixel reached 12 million. There is a fixed focal length and autofocus, Product size is diversified, the same pixel size can be selected, the product size is 6mmX6mm, 12mmX12mm, 23mmX23mm, 28mmX28mm, 32mmX32mm, 38mmX38mm, etc.At the same time, the size can be extremely small, and it can be said that the smallest products on the market currently (only AHD / USB / CVBS, no storage, no transmission function).Which can be independently selected according to the application scenario.

Support and Services:

The USB Camera Module is a high-performance camera solution designed for various industrial applications. It features a compact design with high-quality image capturing capabilities, making it an ideal choice for machine vision, surveillance, and medical imaging systems.

Our product technical support and services for the USB Camera Module include:

  • Assistance with camera integration and software development
  • Product documentation and user manuals
  • Technical troubleshooting and issue resolution
  • Customization and OEM services
  • Product training and education

Our team of experienced engineers and support staff are dedicated to providing excellent customer service and ensuring that our customers get the most out of their USB Camera Module.
